Two classes of window functions
- Authors: Lerner Z.D.
- Issue: Vol 69, No 5 (2024)
- Pages: 435-440
- Section: ТЕОРИЯ И МЕТОДЫ ОБРАБОТКИ СИГНАЛОВ
- URL: https://permmedjournal.ru/0033-8494/article/view/650674
- DOI: https://doi.org/10.31857/S0033849424050052
- EDN: https://elibrary.ru/ILJZBL
- ID: 650674
Cite item
Open Access
Access granted
Abstract
Two new classes of window functions, a special case of each of which is the Kaiser window taken as a sample, are proposed and investigated. In each class, we experimentally find suboptimal windows with the level of the maximum side lobe of the spectrum smaller than that of a sample with the same main lobe width and window duration.
Full Text
About the authors
Z. D. Lerner
Author for correspondence.
Email: lerner269@gmail.com
Russian Federation
References
- Дворкович В.П., Дворкович А.В. Оконные функции для гармонического анализа сигналов. М.: Техносфера, 2016.
- Корн Г., Корн Т. Справочник по математике. М.: Физматлит, 1970.
- Диткин В.А., Прудников А.П. Интегральные преобразования и операционное исчисление. М.: Физматлит, 1961
Supplementary files
Supplementary Files
Action
1.
JATS XML
2.
Fig. 1. Window functions of the suboptimal φ-class window for α = 3.07 (1), 4.05 (3) and 5.02 (5), Kaiser window functions for αk = 3 (2), 4 (4) and 5 (6), for all curves ≤ = 1.
Download (17KB)
3.
Fig. 2. Spectra of the window function of the suboptimal φ-class window for α = 3.07 (1) and the Kaiser window function for αk = 3 (2), for both curves β = 1.
Download (16KB)
4.
Fig. 3. Spectra of the window function of the suboptimal φ-class window for α = 4.05 (1) and the Kaiser window function for αk = 4 (2), for both curves β = 1.
Download (15KB)
5.
Fig. 4. Spectra of the window function of the suboptimal φ-class window for α = 5.02 (1) and the Kaiser window function for αk = 5 (2), for both curves β = 1.
Download (2KB)
6.
Fig. 5. Spectra of the window function of the suboptimal Ψ-class window for α = α = 3.1225 (1) and the Kaiser window function for αk = 3 (2), for both curves β = 1.
Download (2KB)
7.
Fig. 6. Spectra of the window function of the suboptimal Ψ-class window for α = 4.0927 (1) and the Kaiser window function for αk = 4 (2), for both curves β = 1.
Download (2KB)
8.
Fig. 7. Spectra of the window function of the suboptimal Ψ-class window for α = 5.0744 (1) and the Kaiser window function for αk = 5 (2), for both curves β = 1.
Download (2KB)
9.
Fig. 8. Window functions of the suboptimal window of the Ψ-class for α = 3.1225 (1) and 4.0927 (3), Kaiser window functions for αk = 3 (2) and 4 (4), for all curves β = 1, the scale on the ordinate axis is linear (a) and logarithmic (b).
Download (30KB)
10.
Fig. 9. Window functions of the suboptimal window of the Ψ-class: α = 5.0744 for β = 1 (1) and 1.5 (3); Kaiser window functions: αk = 5 for β = 1 (2) and 1.5 (4); for all curves, the scale along the ordinate axis is linear (a) and logarithmic (b).
Download (29KB)
11.
Fig. 10. Spectra of window functions of the suboptimal window of the Ψ-class: α = 5.0744 for β = 1 (1) and 1.5 (3); spectra of window functions of the Kaiser window: αk = 5 for β = 1 (2) and 1.5 (4).
Download (16KB)
12.
