Effect of symmetrical biaxial tension on the magnetic properties of the composite specimen of two steel plates with different mechanical and magnetic properties

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription Access

Abstract

The results of studying the behavior of the magnetic characteristics of two-layer material containing layers of annealed sheet low-carbon Steel 15 and sheet metastable austenitic 12Kh18N9Т steel, subjected to cold rolling with a compression of 50 %, under biaxial symmetric tension have been presented. Experiments on biaxial deformation were carried out on the original biaxial testing machine, allowed to determine the physical properties of materials during elastic-plastic deformation independently along two axes. It has been shown that the coercive force of the studied two-layer material vary monotonically over the entire range of elastic-plastic biaxial deformation and can be used as an informative parameter for assessing the it’s stresses and deformations.
