Application of Some Techniques Using Synchrotron Radiation to the Study of a Promising Composite Thermoelectric Material SrTiO3–TiO2

封面

如何引用文章

全文:

开放存取 开放存取
受限制的访问 ##reader.subscriptionAccessGranted##
受限制的访问 订阅存取

详细

The results of a study of biphase ceramics SrTiO3–TiO2, previously proposed as a promising n-type thermoelectric material, obtained using synchrotron radiation techniques at the shared research center “Siberian Synchrotron and Terahertz Radiation Center”, are presented. In particular, it has been demonstrated by in-situ heating X-ray diffraction that the reaction between the powder components SrCO3 (strontianite) and TiO2 (anatase) to obtain SrTiO3 (tausonite) is not the driving force in the preparation of ceramics by spark plasma sintering of the reaction mixture. For two spectral methods – X-ray luminescence and XANES spectroscopy, the spectrum of biphasic ceramics was compared with a model spectrum obtained from the spectra of single-phase ceramics as reference samples. The X-ray luminescence method revealed a shift to the high-energy region and a narrowing of the spectrum of biphase ceramics, which may indicate size quantization (the presence of a two-dimensional electron gas) in the system. Changes were found in the XANES spectrum of biphase ceramics in the region in which its shape can significantly depend on the symmetry of the nearest environment of Ti4+ atoms. However, it is difficult to interpret these data without numerical simulation.

作者简介

A. Zavjalov

SEC “Advanced Ceramic Materials”, Far Eastern Federal University; Institute of Solid-State Chemistry and Mechanochemistry SB RAS

编辑信件的主要联系方式.
Email: Zav_Alexey@list.ru
Russia, 690922, Vladivostok; Russia, 630128, Novosibirsk

G. Lyubas

Institute of Solid-State Chemistry and Mechanochemistry SB RAS

编辑信件的主要联系方式.
Email: sciencenano@yandex.ru
Russia, 630128, Novosibirsk

M. Sharafutdinov

Institute of Solid-State Chemistry and Mechanochemistry SB RAS; Synchrotron Radiation Facility SKIF, Boreskov Institute of Catalysis SB RAS

编辑信件的主要联系方式.
Email: Marat@solid.nsc.ru
Russia, 630128, Novosibirsk; Russia, 630559, Novosibirsk

V. Kriventsov

Boreskov Institute of Catalysis SB RAS

编辑信件的主要联系方式.
Email: Kriven@mail.ru
Russia, 630090, Novosibirsk

D. Kosyanov

SEC “Advanced Ceramic Materials”, Far Eastern Federal University

编辑信件的主要联系方式.
Email: Kosianov.diu@dvfu.ru
Russia, 690922, Vladivostok

参考

  1. Snyder G.J., Toberer E.S. // Nat. Mater. 2008. V. 7. P. 105. https://doi.org/10.1038/nmat2090
  2. Tritt T.M., Subramanian M.A. // MRS Bull. 2006. V. 31. P. 188. https://doi.org/10.1557/mrs2006.44
  3. Snyder G.J., Christensen M., Nishibori E., Caillat T., Iversen B.B. // Nat. Mater. 2004. V. 3. P. 458. https://doi.org/10.1038/nmat1154
  4. Venkatasubramanian R., Siivola E., Colpitts T., O’Quinn B. // Nature. 2001. V. 413. P. 597. https://doi.org/10.1038/35098012
  5. Hsu K.F., Loo S., Guo F., Chen W., Dyck J.S., Uher C., Hogan T., Polychroniadis E.K., Kanatzidis M.G. // Science. 2004. V. 303. P. 818. https://doi.org/10.1126/science.1092963
  6. Zhao L.-D., Lo S.-H., Zhang Y., Sun H., Tan G., Uher C., Wolverton C., Dravid V.P., Kanatzidis M.G. // Nature. 2014. V. 508. P. 373. https://doi.org/10.1038/nature13184
  7. Zhao L.-D., Tan G., Hao S., He J., Pei Y., Chi H., Wang H., Gong S., Xu H., Dravid V.P., Uher C., Snyder G., Wolverton J.C., Kanatzidis M.G. // Science. 2016. V. 351. P. 141. https://doi.org/10.1126/science. aad3749
  8. Rhyee J.-S., Lee K.H., Lee S.M., Cho E., Kim S.I., Lee E., Kwon Y.S., Shim J.H., Kotliar G. // Nature. 2009. V. 459. P. 965. https://doi.org/10.1038/nature08088
  9. Chung D.-Y., Hogan T., Brazis P., Rocci-Lane M., Kannewurf C., Bastea M., Uher C., Kanatzidis M.G. // Science. 2000. V. 287. P. 1024. https://doi.org/10.1126/science.287.5455.1024
  10. Raj B., van de Voorde M., Mahajan Y. Nanotechnology for Energy Sustainability. Weinheim: Wiley-VCH, 2017. https://doi.org/10.1002/9783527696109
  11. Kim S.I., Lee K.H., Mun H.A., Kim H.S., Hwang S.W., Roh J.W., Yang D.J., Shin W.H., Li X.S., Lee Y.H., Snyder G.J., Kim S.W. // Science. 2015. V. 348. P. 109. https://doi.org/10.1126/science.aaa4166
  12. Nolas G.S., Sharp J., Goldsmid H.J. Thermoelectrics: Basic Principles and New Materials Developments. Berlin, Heidelberg: Springer–Verlag, 2001. https://doi.org/10.1007/978-3-662-04569-5
  13. Zavjalov A., Tikhonov S., Kosyanov D. // Materials. 2019. V. 12. P. 2895. https://doi.org/10.3390/ma12182895
  14. Ohta H., Kim S., Mune Y., Mizoguchi T., Nomura K., Ohta S., Nomura T., Nakanishi Y., Ikuhara Y., Hirano M., Hosono H., Koumoto K. // Nat. Mater. 2007. V. 6. P. 129. https://doi.org/10.1038/nmat1821
  15. Zhang R., Wang C., Li J., Koumoto K. // J. Am. Ceram. Soc. 2010. V. 93. № 6. P. 1677. doi . 03619.xhttps://doi.org/10.1111/j.1551-2916.2010
  16. Safronova N.A., Kryzhanovska O.S., Dobrotvorska M.V., Balabanov A.E., Tolmachev A.V., Yavetskiy R.P., Parkhomenko S.V., Brodskii R.Ye., Baumer V.N., Kosyanov D.Yu., Shichalin O.O., Papynov E.K., Li J. // Ceram. Int. 2020. V. 46. P. 6537. https://doi.org/10.1016/j.ceramint.2019.11.137
  17. Zavjalov A.P., Shichalin O.O., Tikhonov S.A., Kosyanov D.Yu. // IOP Conf. Ser.: Mater. Sci. Eng. 2021. V. 1093. P. 012034. https://doi.org/10.1088/1757-899X/1093/1/012034
  18. Tikhonov S.A., Zavjalov A.P., Kosyanov D.Yu. // IOP Conf. Ser.: Mater. Sci. Eng. 2021. V. 1093. P. 012031. https://doi.org/10.1088/1757-899X/1093/1/012031
  19. Piminov P.A., Baranov G.N., Bogomyagkov A.V. et al. // Phys. Procedia. 2016. V. 84. P. 19. https://doi.org/10.1016/j.phpro.2016.11.005
  20. Ancharov A.I., Baryshev V.B., Chernov V.A. et al. // Nucl. Instrum. Methods Phys. Res. A. 2005. V. 543. № 1. P. 1. https://doi.org/10.1016/j.nima.2005.01.021
  21. Evdokov O.V., Titov V.M., Tolochko B.P., Sharafutdinov M.R. // Nucl. Instrum. Methods Phys. Res. A. 2009. V. 603. № 1–2. P. 194. https://doi.org/10.1016/j.nima.2009.03.001
  22. Aulchenko V.M., Evdokov O.V., Kutovenko V.D., Pirogov B.Ya., Sharafutdinov M.R., Titov V.M., Tolochko B.P., Vasiljev A.V., Zhogin I.A., Zhulanov V.V. // Nucl. Instrum. Methods Phys. Res. A. 2009. V. 603. № 1–2. P. 76. https://doi.org/10.1016/j.nima.2008.12.164
  23. Wojdyr M. // J. Appl. Crystallogr. 2010. V. 43. P. 1126. https://doi.org/10.1107/S0021889810030499
  24. Klementiev K.V. VIPER. (Visual Processing in EXAFS Researches) for Windows. Users Manual and Tutorial with Comments on Analysis Methods in EXAFS. Version of manual 2.20. Version of program 11.00. Barcelona, Spain: 2012. 54 p. https://intranet.cells.es/Beamlines/CLAESS/software/VIPERmanual220.pdf.
  25. Klementiev K.V. XANES Dactyl scope. A Program for Quick and Rigorous XANES Analysis for Windows. Users Manual and Tutorial. Version of manual 1.10. Version of program 6.00. Barcelona, Spain: 2012. 23 p. https://intranet.cells.es/Beamlines/CLAESS/software/ XDmanual110.pdf.
  26. Lyubas G.A., Ledentsov N.N., Litvinov D., Gerthsen D., Soshnikov I.P., Ustinov V.M. // J. Exp. Theor. Phys. 2002. V. 75. P. 179. https://doi.org/10.1134/1.1475718
  27. Tsodikov M.V., Slivinskii E.V., Yushchenko V.V., Kitaev L.E., Kriventsov V.V., Kochubey D.I., Teleshev A.T. // Russ. Chem. Bull. 2000. V.49. № 12. P. 2003. https://doi.org/10.1023/A:1009567807897
  28. Kriventsov V.V., Kochubey D.I., Tsodikov M.V., Navio J. // Nucl. Instrum. Methods Phys. Res. A. 2001. V. 470. № 1–2. P. 331. https://doi.org/10.1016/S0168-9002(01)01068-3
  29. Kriventsov V.V., Kochubey D.I., Tsodikov M.V., Navio J.A., Restrepo G., Macias M. // Nucl. Instrum. Methods Phys. Res. A. 2001. V. 470. № 1–2. P. 347. https://doi.org/10.1016/S0168-9002(01)01072-5
  30. Trukhan N.N., Romannikov V.N., Shmakov A.N., Vanina M.P., Paukshtis E.A., Bukhtiyarov V.I., Kriventsov V.V., Danilov I.Y., Kholdeeva O.A. // Micropor. Mesopor. Mater. 2003. V. 59. № 2–3. P. 73. https://doi.org/10.1016/S1387-1811(03)00287-7
  31. Kholdeeva O.A., Mel’gunov M.S., Shmakov A.N., Trukhan N.N., Kriventsov V.V., Zaikovskii V.I., Malyshev M.E., Romannikov V.N. // Catal. Today. 2004. V. 91–92. P. 205. https://doi.org/10.1016/j.cattod.2004.03.034
